Angle Adjustable Medical Roll Stand (24” Base)

Item No.：IMS-003B
● Anti-fall-off Screw Knob
● Tiltable Monitor / Instrument Holder with Slide-in
　Mounting Plate
● Multi-purpose Utility Basket
● Tip resistant 5-Legged Aluminum Base
● Easy Height Adjustment
● Noiseless and Easy Roll Twin Caster
● Cost-Effective Shipping Solution

The listed spec. can be customized based on your requirement.

Specification

Description

Better Enterprise Angle Adjustable Medical Roll Stand (24” Base) is designed to mount various monitor and medical instruments according to customers request and provide the best viewing angle for users. There is optional counter weight for better performance with heavier medical device.

		Tiltable Monitor / Instrument Holder with Slide-in Mounting Plate The Angle Adjustable Medical Roll Stand (24” Base) features a tilting quick-release slide mount which does not only enables effortless display positioning and best viewing angle for users, but also allows the monitor / instrument be quickly removed and re-attached during transport. The mounting plate can be customized according to your bottom mounted devices.

		Multi-purpose Utility Basket The multi-purpose utility basket does not only allow you to storage the necessary medical accessories well but also feature the tubular grip handle and hooks to enhance the mobility and cable management.

		Anti-fall-off Screw Knob The anti-fall-off screw knob of the angle adjustable medical roll stand is Better Enterprise’s exclusive design. The unique design allows the angle adjustable medical roll stand users to adjust the pole height easily. The screw knob will not fall off even when the users turn it to the last thread. This user-friendly design not only saves pick up time for the angle adjustable medical roll stand users but also lowers the probability of losing the screw knob.

Tip resistant 5-Legged Aluminum Base

The low-center-of-gravity design of 5-legged aluminum base for Angle Adjustable Medical Roll Stand (24” Base) creates easier, more stable mobility and reduce the risk of tipping.

Easy Height Adjustment

The unique height adjustment design makes it much easier to adjust the height of the table top according to the application environment.

Besides, there is also the optional Pneumatic Height Adjustment System.

Noiseless and Easy Roll Twin Casters

The selected 3" twin wheel, soft casters allow you to easily move this stand quietly and quickly. Two lockable casters secure the stand in place.

Cost-Effective Shipping Solution

Better Enterprise devotes itself to minimizing the packaging dimension and using less packaging material by its unique parts and components design that reduce the shipping cost and make environment friendly possible.

Have more requirements for Medical Roll Stand?

With strong design ability and a wide variety of accessories available, Better Enterprise is also able to create the Medical Roll Stand that is tailored to the specific needs of your healthcare environment. Contact us and let us help you built the cart to best accommodate your equipment.

choose Better, always better!

Specification

Item Name			Angle Adjustable Medical Roll Stand (24” Base)
Item No.			IMS-003B
Height (From floor to top)			28.5" ~ 47.8" (725 mm ~ 1215 mm)
Dimension	Base		24” with 5-Legs
	Caster		3” twin-casters (2 pcs with brakes)
	Pole	Top	Ø 1-1/2” (38.1 mm)
		Bottom	Ø 2” (50.8 mm)
Material	Base		Powder coated aluminum
	Pole	Top	Stainless steel
		Bottom	Anodized aluminum
	Monitor / Instrument Holder		Anodized aluminum
	Utility Basket		Powder coated steel
